The Miata

Part List:

  1. Control tyres for Miata Trophy are Toyo Proxes R888R for dry & wet conditions. The permitted tyre size is NA Class: 195/50/15 and NC Class: 215/45/17, with all tyres having to be purchased via the official tyre distributor.

  2. Wheels are free subject to the following requirements:

NA Class mk1 wheels must be: 15” x 7J et25-30

NC Class mk3 Wheels must be: Mazda MX5 17” x 7J

      Style 1: Part Number 9966-36-7070

      Style 2: Part Number 9965-38-7070

      Style 3: Part Number 9965-45-7070

      OR Rota “Force” - 17” x 7.5J - 45mm offset Rota “Torque” - 17.5” x 7.5J - 45mm offset.

  1. Bushes may be upgraded to Polyurethane, subject to the retention of the standard fitting positions.
  2. The control suspension is GAZ Gold coilovers in all cases. Gaz seals must be fitted and intact at all times.
  3. Towing eyes must be fitted front & rear and must comply with Motorsport UK Regulation. Wire towing straps in accordance with Motorsport UK regulation Q.13.1.3(b) are preferred.
  4. A wide angle rear view interior mirror is recommended.
  5. Towing eyes must be fitted front & rear and must comply with Motorsport UK Regulation. Wire towing straps in accordance with Motorsport UK regulation Q.13.1.3(b) are preferred.
  6. Cars are not permitted to compete with roofs attached.

Classed Miata Trophy entrants must compete in either a standard mk1 MX5 Chassis Code NA or standard MK3 MX5 Chassis Code NC (including NC2 or NC3), in right hand drive only. The original silhouette must be maintained, except the variation caused by the fitment of approved front chin spoiler and/or the fitting of wire towing straps in accordance with Motorsport UK regulation Q13.1.3(b).

Cars must be presented to a high standard. Unpainted panels, unrepaired damage or cars not achieving a satisfactory level of preparation and presentation, as judged by the championship scrutineer, may receive a warning and may ultimately result in disqualification.

In addition to the control items highlighted on the image above, there are a few general requirements from Motorsport UK, the UKs governing body:

GENERAL SAFETY REQUIREMENTS:

The following articles of the Motorsport UK Blue Book ‘Section K Competitors: Safety’ are highlighted as being applicable, but not to the exclusion of any other.

Motorsport UK General Regulations that automatically apply:

K 2.1.2 - K 2.1.4 - Seat belts, 4, 5 and 6 point harnesses

K 3.1 - Fire extinguisher, Appendix 1, Table 3 , references (3.1.2 a) &/or (3.1.2 b) apply

K 5.1 & K 5.2 - Red warning light (Rain Light)

K 6 - Fuel Tanks & Fillers

K 8 - External Circuit Breaker (see also G120 & 121)

K 9 – Race Overalls (in particular, K 9.1.1)

K 10 – Crash Helmets

K 13, - Frontal Head Restraints (HANS device)

Safety Harnesses: In order to maintain the integrity of the harness system in the event of an accident, it is recommended that these should be a minimum of five-point attachment, in accordance with Q 13.10.2.

Seats: It is strongly recommended that seats have side wings or side head restraints to take into account lateral forces.

ADVERTISING:

Advertising on vehicles is subject to requirements set out in Motorsport UK Yearbook Q 19.2.2 and H 28 & H 29 in particular. For the avoidance of doubt, use of the side windows for advertising is strictly prohibited.

An Miata Trophy championship sticker set will be distributed in advance of the first round of each season. This will include, but is not limited to stickers in the following positions:

  • Windscreen top
  • Front and Rear number plates
  • Number Board

Black race numbers on a white number board must be located on both driver and passenger door – the number on the bonnet may be substituted for reflective yellow number on the windscreen on the passenger side under the screen top (as required by Section Q 11.4 of the Motorsport UK Yearbook). An additional car number should be run on the rear profile of the vehicle.

For full regulations, visit HERE.
